CFAIR 120 cfm portable air compressor is well designed by Caifull, diesel injected, rotray screw compressor. Driven by powerful 4-cylinder ISUZU engine, used in efficiency and less fuel consumption.
Yanmar engine
175 CFM
100 PSI
2.4 gal/hr @ full load
1.7 gal/hr @ 70% load
62 dBA noise level
126 PSIG max working pressure
3/4" Male Valve x 2
2" Female Valve x 1
SAE Brake HP 53.9
23.8 Gallon Fuel Tank
All portable air compressor China models are based on well proven designs and widely distributed throughout the rest of the world. Thousands of these units are already working under the most demanding conditions in construction, mining and industrial applications all over the world. With a comprehensive array of standard features, the CFAIR Series diesel powered air compressor represents outstanding value for money in capital investment terms. And their high levels of fuel efficiency and
reliability deliver whole-of-life operating costs that are amongst the lowest available.
| MODEL | CF120MI-7 | |
| Air End Type | Rotary Twin Screw, Single stage | |
| Air Outlets | 3/4'' x 2 | |
| Free Air Delivery | CFM (mm³/min) | 120 (3.4) |
| Working Pressure | bar (psi) | 7 (101.5) |
| Engine Model | ISUZU | |
| Fuel | Diesel | |
| Emission | China Stage II | |
| Engine Type | 4 cylinder, Direct-injection | |
| Displacement | L | 2.771 |
| L X W X H | mm | 3066*1456*1587 |
| Weight | kg | 1000 |
Note: Please feel free to contact us if any more customized requirements!
CFAIR 120cfm portable air compressor is widely used in mining industry. The value of mineral resources is huge, and many complex construction problems will be encountered during the mining process of mines. For example, there is no air inside the mountain range, and there will be a lack of air in the mine after the mine is opened. At this time, an air compressor will be used. Furthermore, there is the issue of energy saving in mines. If electric energy is used, it means that the location cannot be moved, and there is a space limitation problem. Diesel mobile screw air compressors are very suitable for this scenario. The CFAIR diesel air compressor factory ensures that each unit meets the highest standards of quality and performance, making it a trusted choice for professionals in the field.
CFAIR recommends some popular products on the market based on customers' actual applications and offers customization services according to specific customer requirements. Simultaneously, CFAIR is committed to customizing machinery based on customers' specific needs. Whether customers require solutions tailored to special environments, specific flow rates, or customized pressure requirements, CFAIR provides personalized customization services, ensuring that products perfectly meet the practical engineering and application needs of customers. Through flexible customization options, CFAIR offers customers a broader range of choices to meet the requirements of different industries and application fields.
