CFAIR 850CFM Screw Compressor is a revolutionary compressor that combines high performance with reliability. Throughout the design and engineering process, CFAIR team design this model to meet the needs of the demanding coal mining and water well drilling segments. Powered by famouse CUMMINS engine, customized airend, latest technology of air filters, all these advantages make it popular among serving customers and drilling contractors in the mining, mineral exploration and quarrying industries.
Model: CF850BF-22
Portable diesel compressor: Box type
Air delivery: 23.9 m³/min | 850 CFM
Pressure: 22 Bar | 319 PSI
Compressor diesel engine: FAWDE
319PSI working pressure
Air flow is 850 CFM(cubic feet per minute)
CUMMINS engine
Customized airend
latest technology of air filters
Loading and unloading the Drill through forklift slots, CFAIR model CF850B-22 is easy to move
| MODEL | CF850BF-22 | |
| Air End Type | Rotary Twin Screw, Single stage | |
| Air Outlets | 3/4'' x 1 + 2'' x 1 | |
| Free Air Delivery | CFM (mm³/min) | 850 (23.9) |
| Working Pressure | bar (psi) | 22 (319.0) |
| Engine Model | China FAWDE | |
| Fuel | Diesel | |
| Emission | China Stage II | |
| Engine Type | 6 cylinder, Direct-injection | |
| Displacement | L | 12.52 |
| L X W X H | mm | 4060*1900*2340 |
| Weight | kg | 3300 |
Note: Please feel free to contact us if any more customized requirements!
CF850BF-22 air compressors are characterized by low emission, low fuel consumption and advanced electronic control. They are widely used in coal mining and water well drilling applications. Model CF850B-22 is truck or excavator-mounted, that allows you to get it easily to the working site. In coal mining applications, CF850B-22 can power 16.5 cm blasthole drilling. 319PSI Screw Compressor is capable of powering water well drilling approx.18-24m at very economic cost. The compact dimensions, lighter weight, performance ability, and fuel efficiency enjoys highly reputtation among customters from coal mining and water well drilling.
CFAIR recommends some popular products on the market based on customers' actual applications and offers customization services according to specific customer requirements. Simultaneously, CFAIR is committed to customizing machinery based on customers' specific needs. Whether customers require solutions tailored to special environments, specific flow rates, or customized pressure requirements, CFAIR provides personalized customization services, ensuring that products perfectly meet the practical engineering and application needs of customers. Through flexible customization options, CFAIR offers customers a broader range of choices to meet the requirements of different industries and application fields.
